Prestazioni eccezionali, audio e video di qualità, connettività affidabile in un design sottile ed elegante: i nuovi notebook Acer Aspire 5745 e 7745 possiedono tutte le caratteristiche per rendere l’intrattenimento un’esperienza indimenticabile.
Aspire 5745 e 7745 possono contare sulla nuova famiglia di processori Intel® Core™ del 2010, a garanzia di ottime prestazioni per applicazioni legate alla musica, al gaming, ai video, ai film, alle foto, ai social network e molte altre ancora. I nuovi processori Intel Core i7 e Core i5 integrano, inoltre, la tecnologia Intel Turbo Boost che accelera dinamicamente le prestazioni in base al carico di lavoro, adeguandole alla reale necessità dell’utente.
La serie è disponibile nei formati di schermo 39.5 cm (15,6”) e 44 cm (17,3”) – con display in alta definizione Acer CineCrystal™ che consentono di ottenere immagini luminose e realistiche. Il formato 16:9 e la risoluzione assicurano invece una visione in alta definizione davvero mozzafiato per un intrattenimento cinematografico estremo.
L’audio coinvolgente vi porterà al centro di ogni scena. Il sistema audio Dolby® surround con due altoparlanti stereo incorporati dotati di Dolby Home Theater® di terza generazione, insieme all’output audio True surround a 5.1 canali, vi avvolgeranno nel suono ad alta definizione più puro. L’eccezionale qualità del suono, insieme alla scelta di soluzioni grafiche all’avanguardia e all’unità Blu-ray Disc™ opzionale, offrono un’esperienza di intrattenimento che coinvolgerà tutti i vostri sensi.
Nell’assicurare intrattenimento e prestazioni, Aspire 5745 e 7745 fanno un ulteriore passo avanti nella riduzione dell’impatto ambientale. Il display sfrutta la tecnologia di retroilluminazione a LED, che consente la riproduzione di immagini ancora più definite, aumenta la visibilità in condizioni di scarsa illuminazione ed essendo privo di mercurio riduce il consumo energetico.
Così come la tecnologia Acer PowerSmart che estende la durata della batteria fino a 8 ore.
Ma Aspire 5745 e 7745 sono anche un piacere per gli occhi. Lo châssis nero, laccato lucido, dalle forme arrotondate offre un tocco di classe ed eleganza. Al suo interno, la tastiera ad alta reattività con tasti più grandi per una digitazione ancora più comoda, e una console media dedicata per il totale controllo su ogni forma di intrattenimento. Il touchpad multi-gesture, con scorrimento pagine mediante movimento circolare e zoom tramite pinch, consente una navigazione rapida e senza problemi con la punta delle dita, mentre i tasti di controllo offrono un facile accesso all’entertainment.
Mentre Aspire 7745 è un ottimo sostituto del desktop, grazie all’ampio display, al massimo delle prestazioni, a due hard disk fino a 1,28 TB, all’audio e video in alta definizione, Aspire 5745 unisce un elevata portabilità con ottime capacità d’elaborazione.
I nuovi notebook offrono fino a 8 GB di memoria DDR3 per risposte ultra-veloci del sistema e una gestione continua di richieste multitasking. L’Aspire 7745 con processori quad-core dispongono di 4 slot di memoria che può così raggiungere anche i 16 GB DDR3.
Per quanto riguarda lo storage, i dischi fissi a capacità elevata offrono moltissimo spazio per salvare con semplicità il vostro archivio digitale in continua crescita. Un lettore di schede multi-in-1, che supporta i formati di schede più usati, consente un trasferimento dei dati facile e veloce.
Le più recenti tecnologie wireless e wired assicurano una connettività totale: connessione di rete 802.11a/b/g/Draft-N Wi-Fi CERTIFIED® che supporta Acer SignalUp™ con tecnologia wireless Nplify™, Bluetooth® 2.1+ opzionale, Gigabit LAN e modem.
La soluzione Acer Video Conference che include la webcam Acer Crystal Eye, il software Acer Video Conference Manager e la tecnologia Acer PureZone, consentono, infine, di mantenersi in contatto con i propri amici e familiari, oppure di produrre videoconferenze di lavoro.
Disponibile solo su alcuni modelli, Acer Arcade™ Deluxe è un portale media unico nel suo genere: una soluzione completa per l’intrattenimento digitale che si avvale di un’interfaccia intuitiva per poter accedere ai propri media preferiti – musica, video, foto, DVD e all’Acer Crystal Eye webcam.
***
Detailed information on Acer products and a catalogue with prices in PDF format are available on Acer’s website www.acer.com
About Acer
Since its founding in 1976, Acer has achieved the goal of breaking the barriers between people and technology. Globally, Acer ranks No. 2 for total PCs and notebooks. A profitable and sustainable Channel Business Model is instrumental to the company’s continuing growth, while its multi-brand approach effectively integrates Acer, Gateway, Packard Bell, and eMachines brands in worldwide markets. Acer strives to design environmentally friendly products and establish a green supply chain through collaboration with suppliers. Acer is proud to be a Worldwide Partner of the Olympic Movement in staging the Vancouver 2010 Olympic Winter and London 2012 Olympic Games. The Acer Group employs 7,000 people worldwide. Estimated revenue for 2009 is US$17.9 billion. See www.acer-group.com for more information.
© 2010 Acer Inc. All rights reserved. Acer and the Acer logo are registered trademarks of Acer Incorporated. Microsoft and Windows are registered trademarks of Microsoft Corporation. Intel and Pentium are registered trademarks of Intel Corporation. Other trademarks, registered trademarks and/or service marks, indicated or otherwise, are the properties of their respective owners.
Aspire 7745G Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 Intel® Core™ i7-820QM processor (8 MB L3 cache, 1.73 GHz with Turbo Boost up to 3.06 GHz, DDR3 1333 MHz, 45 W), i7-720QM processor (6 MB L3 cache, 1.60 GHz with Turbo Boost up to 2.80 GHz, DDR3 1333 MHz, 45 W), i7-620M processor (4 MB L3 cache, 2.66 GHz with Turbo Boost up to 3.33 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core™ i5-430M/ i5-520M/i5-540M processor (3 MB L3 cache, 2.26/2.40/2.53 GHz with Turbo Boost up to 2.53/2.93/3.06 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core™ i3-330M/i3-350M processor (3 MB L3 cache, 2.13/2.26 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
System memory1, 3, 5 Dual-channel DDR3 SDRAM support (for dual-core processors):
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 8 GB using two soDIMM modules4
Dual-channel DDR3 SDRAM support (for quad-core processors):
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 16 GB using four soDIMM modules4
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 8 GB using four soDIMM modules4
Display 17.3″ HD+ 1600 x 900 pixel resolution, high-brightness (220-nit) Acer CineCrystal™ LED-backlit TFT LCD
16:9 aspect ratio
8 ms high-def response time
60% color gamut
Graphics1 ATI Mobility Radeon™ HD 5850 with 1024 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
ATI Mobility Radeon™ HD 5650 with 1024 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
ATI Mobility Radeon™ HD 5470 with 512 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
Dual independent display support
16.7 million colors
External resolution / refresh rates6:
• VGA port up to 2048 x 1536: 85 Hz
• HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
VC-1 and H.264 (AVC) decoding
Microsoft® DirectX® Video Acceleration (DXVA) application interface (API)
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Dolby®7-optimized surround sound system with two built-in stereo speakers and one subwoofer supporting low-frequency effects
Optimized 3rd Generation Dolby Home Theater®7 audio enhancement, featuring Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Audio Optimization, Dolby® High Frequency Enhancer technologies8
True5.1-channel surround sound output
High-definition audio support
Built-in microphone
S/PDIF (Sony/Philips Digital Interface)9 support for digital speakers
MS-Sound compatible
Storage One or two 160/250/320/500 GB or larger hard disk drive1, 10
Multi-in-1 card reader, supporting Secure Digital™ (SD), MultiMediaCard™ (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive1 4X Blu-ray Disc™ writer/DVD-Super Multi double-layer drive
4X Blu-ray Disc™/DVD-Super Multi double-layer drive
8X DVD-Super Multi double-layer drive
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye high-definition webcam with 1280 x 1024 resolution
WLAN1, 11, 12:
• Intel® Centrino® Wireless-N 1000 b/g/n Wi-Fi CERTIFIED™ with Acer Nplify™ featuring MIMO technology
• Acer InviLink™ Nplify™ 802.11 b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1: Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control1 BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight1 410 (W) x 286 (D) x 35/41.5 (H) mm (16.14 x 11.25 x 1.37/1.63 inches)
3.25 kg (7.1 lbs.) with one HDD and 6-cell battery pack13
Power adapter and battery1 ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 120 W AC adapter:
• 155 (W) x 67 (D) x 36.5 (H) mm (6.1 x 2.63 x 1.43 inches)
• 570 g (1.25 lbs.)13 with 180 cm DC cable
3-pin 90 W AC adapter:
• 133 (W) x 59 (D) x 31 (H) mm (5.23 x 2.32 x 1.22 inches)
• 390 g (0.86 lbs.)13 with 180 cm DC cable
3-pin 65 W AC adapter:
• 108 (W) x 46 (D) x 29.5 (H) mm (4.25 x 1.81 x 1.16 inches)
• 225 g (0.49 lbs.)13 with 180 cm DC cable
Acer QuicCharge™ technology14:
• 80% charge in 1 hour
• 2-hour rapid charge system-off
48.8 W 4400 mAh 6-cell Li-ion battery pack
Estimated battery life: Up to 2.5 hours15
ENERGY STAR®
Special keys and controls1 103-/104-/107-key keyboard, with inverted “T” cursor layout
Multi-gesture touchpad pointing device supporting scroll, pinch, rotate, flip
10 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Acer Programmable Key1
Media keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Four USB 2.0 ports
External display (VGA) port
HDMI™ port with HDCP support
Headphone/speaker/line-out jack with S/PDIF support
Microphone-in jack
Ethernet (RJ-45) port
Modem (RJ-11) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Acer PowerSmart Manager1
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google™ Setup
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial1 (Service Pack 2)
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 91
• Microsoft® Works 8.51
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite 2009 Trial16
• McAfee® Virus Definitions
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Acer Arcade™ Deluxe
• NTI Media Maker™
Gaming
• Oberon GameZone Acer Edition1 (except US, Canada, Hong Kong, Korea)
• WildTangent® Acer Edition1 (US, Canada only)
Communication and ISP
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Utilities and tools
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB DDR3 1066 MHz soDIMM module
6-cell Li-ion battery pack
3-pin 65 W / 90 W / 120 W AC adapter
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
1. Specifications vary depending on model.
2. 64-bit software is required to enjoy the advantages of 64-bit processing.
3. Up to 1 GB of available system memory may be allocated for system resource requirements.
4. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
5. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
6. Resolution/refresh rates depend on display capability and color/depth settings.
7. Dolby® is a registered trademark of Dolby® Laboratories. Dolby® Home Theater® is a trademark of Dolby® Laboratories.
8. Dolby® Pro Logic® and the double-D symbol are registered trademarks of Dolby® Laboratories.
9. Supports 7.1-channel surround sound and 2-channel stereo output (multiple streaming).
10. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and the operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
11. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11a/b/g/n and 802.11b/g standards.
12. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
13. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
14. Supported on 4400, 4800 and 5200 mAh battery packs only.
15. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
16. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
Aspire 7745 Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 Intel® Core™ i7-620M processor (4 MB L3 cache, 2.66 GHz with Turbo Boost up to 3.33 GHz, DDR3 1066 MHz, 35 W) supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core™ i5-430M/ i5-520M/i5-540M processor (3 MB L3 cache, 2.26/2.40/2.53 GHz with Turbo Boost up to 2.53/2.93/3.06 GHz, DDR3 1066 MHz, 35 W) supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core™ i3-330M/i3-350M processor (3 MB L3 cache, 2.13/2.26 GHz, DDR3 1066 MHz, 35 W) supporting Intel® 64 architecture, Intel® Smart Cache
System memory1, 3, 5 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 8 GB using two soDIMM modules4
Display 17.3″ HD+ 1600 x 900 pixel resolution, high-brightness (220-nit) Acer CineCrystal™ LED-backlit TFT LCD
16:9 aspect ratio
8 ms high-def response time
60% color gamut
Graphics1 Intel® HD Graphics with 128 MB of dedicated system memory, supporting Microsoft® DirectX® 10
Dual independent display support
16.7 million colors
External resolution / refresh rates6:
• VGA port up to 2560 x 1600: 60 Hz
• HDMI™ port up to 1920 x 1200: 60 Hz
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Dolby®7-optimized surround sound system with two built-in stereo speakers and one subwoofer supporting low-frequency effects
Optimized 3rd Generation Dolby Home Theater®7 audio enhancement, featuring Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Audio Optimization, Dolby® High Frequency Enhancer technologies8
True5.1-channel surround sound output
High-definition audio support
Built-in microphone
S/PDIF (Sony/Philips Digital Interface)9 support for digital speakers
MS-Sound compatible
Storage One or two 160/250/320/500 GB or larger hard disk drive1, 10
Multi-in-1 card reader, supporting Secure Digital™ (SD), MultiMediaCard™ (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™ writer/DVD-Super Multi double-layer drive
4X Blu-ray Disc™1/DVD SuperMulti double-layer drive
8X DVD-Super Multi double-layer drive
Communication1 Acer Video Conference1, featuring:
• Acer Crystal Eye high-definition webcam with 1280 x 1024 resolution
WLAN1, 11, 12:
• Intel® Centrino® Wireless-N 1000 b/g/n Wi-Fi CERTIFIED™ with Acer Nplify™ featuring MIMO technology
• Acer InviLink™ Nplify™ 802.11 b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1: Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control1 BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight1 410 (W) x 286 (D) x 35/41.5 (H) mm (16.14 x 11.25 x 1.37/1.63 inches)
3.25 kg (7.1 lbs.) with one HDD and 6-cell battery pack13
Power adapter and battery1 ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 65 W AC adapter:
• 108 (W) x 46 (D) x 29.5 (H) mm (4.25 x 1.81 x 1.16 inches)
• 225 g (0.49 lbs.)13 with 180 cm DC cable
48.8 W 4400 mAh 6-cell Li-ion battery pack
Estimated battery life: Up to 2.5 hours14
ENERGY STAR®
Special keys and controls1 103-/104-/107-key keyboard with inverted “T” cursor layout
Multi-gesture touchpad pointing device supporting scroll, pinch, rotate, flip
10 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Acer Programmable Key
Media keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Four USB 2.0 ports
External display (VGA) port
HDMI™ port with HDCP support
Headphone/speaker/line-out jack with S/PDIF support
Microphone-in jack
Ethernet (RJ-45) port
Modem (RJ-11) port
DC-in jack for AC adapter
Software1 Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Acer PowerSmart Manager1
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google™ Setup
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial (Service Pack 2) 1
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 91
• Microsoft® Works 8.51
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite 2009 Trial15
• McAfee® Virus Definitions
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Acer Arcade™ Deluxe
• NTI Media Maker™
Gaming
• Oberon GameZone Acer Edition1 (except US, Canada, Hong Kong, Korea)
• WildTangent® Acer Edition1 (US, Canada only)
Communication and ISP
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Utilities and tools
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB DDR3 1066 MHz soDIMM module
6-cell Li-ion battery pack
3-pin 65 W AC adapter
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
1. Specifications vary depending on model.
2. 64-bit software is required to enjoy the advantages of 64-bit processing.
3. Up to 1 GB of available system memory may be allocated for system resource requirements.
4. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
5. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
6. Resolution/refresh rates depend on display capability and color/depth settings.
7. Dolby® is a registered trademark of Dolby® Laboratories. Dolby® Home Theater® is a trademark of Dolby® Laboratories.
8. Dolby® Pro Logic® and the double-D symbol are registered trademarks of Dolby® Laboratories.
9. Supports 7.1-channel surround sound and 2-channel stereo output (multiple streaming).
10. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and the operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
11. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11a/b/g/n and 802.11b/g standards.
12. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
13. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
14. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
15. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
Aspire 5745G Specifications
Operating system1 Genuine Windows® 7 Home Basic 64-bit2
Genuine Windows® 7 Home Premium 64-bit2
CPU/chipset1 Intel® Core™ i7-820QM processor (8 MB L3 cache 1.73 GHz with Turbo Boost up to 3.06 GHz, 45 W), i7-720QM processor (6 MB L3 cache 1.60 GHz with Turbo Boost up to 2.80 GHz, 45 W)
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM modules5
• Up to 4 GB of DDR3 system memory, upgradable to 16 GB using four soDIMM modules5
• Up to 4 GB of DDR3 system memory, upgradable to 8 GB using four soDIMM modules5
Note: Four soDIMM modules only in Quad core SKU or above.
Display 15″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD, supporting simultaneous multi-window viewing
Mercury free, environment friendly
16:9 aspect ratio
Super-slim design
Graphics NVIDIA® GeForce® GT 330M with up to 46066 MB of TurboCache™ (1024 MB of dedicated DDR3 VRAM, up to 35824 MB of shared system memory), supporting NVIDIA® CUDA™, PhysX™, PureVideo® HD technology, OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.0, Microsoft® DirectX® 10.1
NVIDIA® GeForce® 310M with up to 40946 MB of TurboCache™ (512 MB of dedicated DDR3 VRAM, up to 35824 MB of shared system memory), supporting NVIDIA® CUDA™, PhysX™, PureVideo® HD technology, OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.0, Microsoft® DirectX® 10.1
Dual independent display support
16.7 million colors
External resolution / refresh rates7:
VGA port up to 2048 x 1536: 85 Hz
HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Optimized 3rd Generation Dolby Home Theater®8 audio enhancement, featuring Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Audio Optimization, Dolby® High Frequency Enhancer technologies9
High-definition audio support
S/PDIF (Sony/Philips Digital Interface)10 support for digital speakers
MS-Sound compatible
Built-in microphone
Storage 160/250/320/500/640 GB or larger hard disk drive1, 11
Multi-in-1 card reader, supporting Secure Digital™ (SD), MultiMediaCard™ (MMC), Memory Stick® (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive1 4X Blu-ray Disc™/DVD-Super Multi double-layer drive
4X Blu-ray Disc™ writer/DVD-Super Multi double-layer drive
8X DVD-Super Multi double-layer drive
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye high-definition webcam with 1280 x 1024 resolution
WLAN1, 12, 13:
• Acer InviLink™ Nplify™ 802.11 b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11 b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:Bluetooth® 2.1+EDR
WPAN1: Bluetooth® 3.0+HS
Wi-Fi®/WiMAX™1, 12, 13:
• Intel® Centrino® Advanced-N + WiMAX™ 625014 with Acer Nplify™, featuring MIMO technology
• Wi-Fi®: 802.11 a/g/n Wi-Fi CERTIFIED™
• WiMAX™: 802.16e/2.5G WiMAX Forum Certified™12, featuring Mobile WiMAX™
• Supporting Acer SignalUp™ wireless technology
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 379 (W) x 250 (D) x 25.5/34.1 (H) mm (14.96 X 9.84 X 1.0/1.34 inches)
2.6 kg (5.72 lbs.) with 6-cell battery15
Power adapter and battery1
ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 90 W AC adapter:
• 133 (W) x 59 (D) x 31 (H) mm (5.23 x 2.32 x 1.22 inches)
• 390 g (0.86 lbs.)15 with 180 cm DC cable
Acer QuicCharge™ technology:
• 80% charge in 1 hour
• 2-hour rapid charge system-off
48.8 W 4400 mAh 6-cell Li-ion battery pack:
Estimated battery life: Up to 3.5 hours16
ENERGY STAR®
Special keys and controls 103-/104-/107-key keyboard, with inverted “T” cursor layout
10 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support,
Media control keys (printed on keyboard): play/pause, stop, previous, next
Multi-gesture touchpad pointing device, featuring Acer FingerNav 4-way control function
Gesture support
• Vertical scrolling
• Pinch-action zoom
• Page flip
• Pivot rotate
Easy-launch buttons: Programmable key
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Four USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack with S/PDIF support
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial (Service Pack 2)
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 9
• Microsoft® Works 8.5
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite Trial17
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Acer Arcade™ Deluxe
• NTI Media Maker™
Gaming
• Oberon GameZone1 (except US, Canada, Hong Kong, Korea)
• WildTangent®1 (US, Canada only)
Communication and ISP
• Acer Crystal Eye
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
• Skype™
Web links and utilities
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 1066 MHz soDIMM module
6-cell Li-ion battery pack
3-pin 90W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
1. Specifications vary depending on model.
2. 64-bit software is required to enjoy the advantages of 64-bit processing.
3. Up to 1 GB of available system memory may be allocated for system resource requirements.
4. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
5. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
6. Total available graphics memory comprises dedicated video memory, system memory, and shared system memory. This figure will vary depending on system memory, installed drivers, BIOS settings and other factors.
7. Resolution/refresh rates depend on display and color/depth settings.
8. Dolby® is a registered trademark of Dolby® Laboratories. Dolby Home Theater® is a trademark of Dolby® Laboratories.
9. Dolby® Pro Logic® and the double-D symbol are registered trademarks of Dolby® Laboratories.
10. Supports 7.1-channel surround sound and 2-channel stereo output (multiple streaming).
11. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and the operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
12. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11a/b/g/n and 802.11b/g standards.
13. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
14. Subject to availability.
15. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
16. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
17. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
Aspire 5745G Specifications
Operating system1 Genuine Windows® 7 Home Basic 64-bit2
Genuine Windows® 7 Home Premium 64-bit2
CPU/chipset1 Intel® Core™ i7-620M processor (4 MB L3 cache, 2.66 GHz with Turbo Boost up to 3.33 GHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core i5-430M/i5-520M/i5-540M processor (3 MB L3 cache, 2.26/2.40/2.53 GHz with Turbo Boost up to 2.53/2.93/3.06 GHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core i3-330M/i3-350M processor (3 MB L3 cache, 2.13/2.26 GHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM modules5
Display 15″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD, supporting simultaneous multi-window viewing
Mercury free, environment friendly
16:9 aspect ratio
Super-slim design
Graphics NVIDIA® GeForce® GT 330M with Switchable™ Graphics technology, up to 46066 MB of TurboCache™ (1024 MB of dedicated DDR3 VRAM, up to 35824 MB of shared system memory), supporting NVIDIA® CUDA™, PhysX™, PureVideo® HD technology, OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.0, Microsoft® DirectX® 10.1
NVIDIA® GeForce® 310M with Switchable™ Graphics technology, up to 40946 MB of TurboCache™ (512 MB of dedicated DDR3 VRAM, up to 35824 MB of shared system memory), supporting NVIDIA® CUDA™, PhysX™, PureVideo® HD technology, OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.0, Microsoft® DirectX® 10.1
Dual independent display support
16.7 million colors
External resolution / refresh rates7:
VGA port up to 2048 x 1536: 85 Hz
HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Optimized 3rd Generation Dolby Home Theater®8 audio enhancement, featuring Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Audio Optimization, Dolby® High Frequency Enhancer technologies9
High-definition audio support
S/PDIF (Sony/Philips Digital Interface)10 support for digital speakers
MS-Sound compatible
Built-in microphone
Storage 160/250/320/500/640 GB or larger hard disk drive1, 11
Multi-in-1 card reader, supporting Secure Digital™ (SD), MultiMediaCard™ (MMC), Memory Stick® (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™/DVD-Super Multi double-layer drive
4X Blu-ray Disc™ writer/DVD-Super Multi double-layer drive
8X DVD-Super Multi double-layer drive
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye high-definition webcam with 1280 x 1024 resolution
WLAN1, 12, 13:
• Acer InviLink™ Nplify™ 802.11 b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11 b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:Bluetooth® 2.1+EDR
WPAN1: Bluetooth® 3.0+HS
Wi-Fi®/WiMAX™1, 12, 13:
• Intel® Centrino® Advanced-N + WiMAX™ 625014 with Acer Nplify™, featuring MIMO technology
• Wi-Fi®: 802.11 a/g/n Wi-Fi CERTIFIED™
• WiMAX™: 802.16e/2.5G WiMAX Forum Certified™12, featuring Mobile WiMAX™
• Supporting Acer SignalUp™ wireless technology
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 379 (W) x 250 (D) x 25.5/34.1 (H) mm (14.96 X 9.84 X 1.0/1.34 inches)
2.6 kg (5.72 lbs.) with 6-cell battery15
Power adapter and battery1
ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 90 W AC adapter:
• 133 (W) x 59 (D) x 31 (H) mm (5.23 x 2.32 x 1.22 inches)
• 390 g (0.86 lbs.)15 with 180 cm DC cable
Acer QuicCharge™ technology:
• 80% charge in 1 hour
• 2-hour rapid charge system-off
48.8 W 4400 mAh 6-cell Li-ion battery pack:
Estimated battery life: Up to 3.5 hours16
ENERGY STAR®
Special keys and controls 103-/104-/107-key keyboard, with inverted “T” cursor layout
10 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support,
Media control keys (printed on keyboard): play/pause, stop, previous, next
Multi-gesture touchpad pointing device, featuring Acer FingerNav 4-way control function
Gesture support
• Vertical scrolling
• Pinch-action zoom
• Page flip
• Pivot rotate
Easy-launch buttons: Power smart key
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Four USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack with S/PDIF support
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial (Service Pack 2)
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 9
• Microsoft® Works 8.5
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite Trial17
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Acer Arcade™ Deluxe
• NTI Media Maker™
Gaming
• Oberon GameZone1 (except US, Canada, Hong Kong, Korea)
• WildTangent®1 (US, Canada only)
Communication and ISP
• Acer Crystal Eye
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
• Skype™
Web links and utilities
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 1066 MHz soDIMM module
6-cell Li-ion battery pack
3-pin 90W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
1. Specifications vary depending on model.
2. 64-bit software is required to enjoy the advantages of 64-bit processing.
3. Up to 1 GB of available system memory may be allocated for system resource requirements.
4. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
5. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
6. Total available graphics memory comprises dedicated video memory, system memory, and shared system memory. This figure will vary depending on system memory, installed drivers, BIOS settings and other factors.
7. Resolution/refresh rates depend on display and color/depth settings.
8. Dolby® is a registered trademark of Dolby® Laboratories. Dolby Home Theater® is a trademark of Dolby® Laboratories.
9. Dolby® Pro Logic® and the double-D symbol are registered trademarks of Dolby® Laboratories.
10. Supports 7.1-channel surround sound and 2-channel stereo output (multiple streaming).
11. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and the operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
12. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11a/b/g/n and 802.11b/g standards.
13. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
14. Subject to availability.
15. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
16. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
17. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
Aspire 5745 Specifications
Operating system1 Genuine Windows® 7 Home Basic 64-bit2
Genuine Windows® 7 Home Premium 64-bit2
CPU/chipset1 Intel® Core™ i7-620M processor (4 MB L3 cache, 2.66 GHz with Turbo Boost up to 3.33 GHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core i5-430M/ i5-520M/i5-540M processor (3 MB L3 cache, 2.26/2.40/2.53 GHz with Turbo Boost up to 2.53/2.93/3.06 GHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core i3-330M/i3-350M processor (3 MB L3 cache, 2.13/2.26 GHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 8 GB using two soDIMM modules5
Display 15″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD, supporting simultaneous multi-window viewing via Acer GridVista™
Mercury free, environment friendly
Super-slim design
16:9 aspect ratio
Graphics Intel® HD Graphics with 128 MB of dedicated system memory, supporting Microsoft® DirectX® 10
Dual independent display support
16.7 million colors
External resolution / refresh rates6:
• VGA port up to 2560 x 1600: 60 Hz
• HDMI™ port up to 1920 x 1200: 60 Hz
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Optimized 3rd Generation Dolby Home Theater®7 audio enhancement, featuring Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Audio Optimization, Dolby® High Frequency Enhancer technologies8
High-definition audio support
S/PDIF (Sony/Philips Digital Interface)9 support for digital speakers
MS-Sound compatible
Built-in microphone
Storage 160/250/320/500/640 GB or larger hard disk drive1, 10
Multi-in-1 card reader, supporting Secure Digital™ (SD), MultiMediaCard™ (MMC), Memory Stick® (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™/DVD-Super Multi double-layer drive
4X Blu-ray Disc™ writer/DVD-Super Multi double-layer drive
8X DVD-Super Multi double-layer drive
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye high-definition webcam with 1280 x 1024 resolution
WLAN1, 11, 12:,
• Acer InviLink™ Nplify™ 802.11 b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11 b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1: Bluetooth® 2.1+EDR
WPAN1: Bluetooth® 3.0+HS
Wi-Fi®/WiMAX™1, 11, 12:
• Intel® Centrino® Advanced-N + WiMAX™ 625013 with Acer Nplify™, featuring MIMO technology
• Wi-Fi®: 802.11 a/g/n Wi-Fi CERTIFIED™
• WiMAX™: 802.16e/2.5G WiMAX Forum Certified™11, featuring Mobile WiMAX™
• Supporting Acer SignalUp™ wireless technology
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 379 (W) x 250 (D) x 25.5/34.1 (H) mm (14.96 X 9.84 X 1.0/1.34 inches)
2.6 kg (5.72 lbs.) with 6-cell battery14
Power adapter and battery1 ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
Acer 3-pin 65 W AC adapter
• 108 (W) x 46 (D) x 29.5 (H) mm (4.25 x 1.81 x 1.16 inches)
225 g (0.49 lbs.)14 with 180 cm DC cable
48.8 W 4400 mAh 6-cell Li-ion battery pack
Estimated battery life: Up to 3.5 hours15
ENERGY STAR®
Special keys and controls 103-/104-/107-key keyboard, with inverted “T” cursor layout
10 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Media control keys (printed on keyboard): play/pause, stop, previous, next
Multi-gesture touchpad pointing device, featuring Acer FingerNav 4-way control function
Gesture support
• Vertical scrolling
• Pinch-action zoom
• Page flip
• Pivot rotate
Easy-launch buttons: Programmable key
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Four USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack with S/PDIF support
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial (Service Pack 2)
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 9
• Microsoft® Works 8.5
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite Trial16
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Acer Arcade™ Deluxe
• NTI Media Maker™
Gaming
• Oberon GameZone1 (except US, Canada, Hong Kong, Korea)
• WildTangent®1 (US, Canada only)
Communication and ISP
• Acer Crystal Eye
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
• Skype™
Web links and utilities
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 1066 MHz soDIMM module
6-cell Li-ion battery pack
3-pin 65 W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
1. Specifications vary depending on model.
2. 64-bit software is required to enjoy the advantages of 64-bit processing.
3. Up to 1 GB of available system memory may be allocated for system resource requirements.
4. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
5. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
6. Resolution/refresh rates depend on display and color/depth settings.
7. Dolby® is a registered trademark of Dolby® Laboratories. Dolby Home Theater® is a trademark of Dolby® Laboratories.
8. Dolby® Pro Logic® and the double-D symbol are registered trademarks of Dolby® Laboratories.
9. Supports 7.1-channel surround sound and 2-channel stereo output (multiple streaming).
10. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and the operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
11. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11a/b/g/n and 802.11b/g standards.
12. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
13. Subject to availability.
14. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
15. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
16. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
Aspire 4745G Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 Intel® Core™ i7-620M processor (4 MB L3 cache, 2.66 GHz with Turbo Boost up to 3.33 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core™ i5-430M/i5-520M/i5-540M processor (3 MB L3 cache, 2.26/2.40/2.53 GHz with Turbo Boost up to 2.53/2.93/3.06 GHz, DDR3 1066 MHz, 35 W) supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core™ i3-330M/i3-350M processor (3 MB L3 cache, 2.13/2.26 GHz, DDR3 1066 MHz, 35 W) supporting Intel® 64 architecture, Intel® Smart Cache
Mobile Intel® HM55 Express Chipset
System memory1, 3, 5 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 8 GB using two soDIMM modules4
Display 14″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD, supporting simultaneous multi-window viewing via Acer GridVista™
16:9 aspect ratio
Super-slim design
Graphics ATI Mobility Radeon™ HD 5650 with Switchable™ Graphics technology, up to 40913 MB of HyperMemory™ (1024 MB of dedicated DDR3 VRAM, up to 30675 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
ATI Mobility Radeon™ HD 5470 with Switchable™ Graphics technology, up to 35793 MB of HyperMemory™ (512 MB of dedicated DDR3 VRAM, up to 30675 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
Dual independent display support
16.7 million colors
External resolution / refresh rates6:
• VGA port up to 2048 x 1536: 85 Hz
• HDMI™ port up to 1920 x 1080 60 Hz
MPEG-2/DVD decoding
VC-1 and H.264 (AVC) decoding
Microsoft® DirectX® Video Acceleration (DXVA) application interface (API)
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Optimized 3rd Generation Dolby® Home Theater®7 audio enhancement features including Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Inverse Filtering, and Dolby® High Frequency Enhancer technologies8
High-definition audio support
Built-in microphone
S/PDIF (Sony/Philips Digital Interface)9 support for digital speakers
MS-Sound compatible
Storage 160/250/320/500/640 GB or larger hard disk drive1, 10
Multi-in-1 card reader, supporting Secure Digital™ (SD), MultiMediaCard™ (MMC), Memory Stick® (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™1/DVD-Super Multi double-layer drive
4X Blu-ray Disc™1 writer/DVD-Super Multi double-layer drive
8X DVD-Super Multi double-layer driveM
Communication1 Acer video conferencing solution1, featuring:
• Acer Crystal Eye high-definition webcam with 1280 x 1024 resolution
WLAN1, 11, 12:
• Acer InviLink™ Nplify™ 802.11 b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1: Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control1 BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 342 (W) x 245 (D) x 21.1/29.1 (H) mm (13.46 x 9.64 x 0.83/1.14 inches)
2.23 kg (4.92 lbs.) with 6-cell battery pack12
Power adapter and battery1 ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 90 W AC adapter:
• 133 (W) x 59 (D) x 31 (H) mm (5.23 x 2.32 x 1.22 inches)
• 390 g (0.86 lbs.)12 with 180 cm DC cable
Acer QuicCharge™ technology13:
• 80% charge in 1 hour
• 2-hour rapid charge system-off
48.8 W 4400 mAh 6-cell Li-ion standard battery pack
Estimated battery life: Up to 6 hours13
ENERGY STAR®
Special keys and controls 86-/87-/91-key keyboard with inverted “T” cursor layout
Multi-gesture touchpad pointing device supporting scroll, pinch, rotate, flip
10 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Acer Programming key
Easy-launch keys: Communication®
Media control keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Four USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker jack with S/PDIF support
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer PowerSmart Manager1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google™ Setup
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial (Service Pack 2)
• Microsoft® Works SE 91
• Microsoft® Works 9
• Microsoft® Works 8.5
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite 2009 Trial15
• McAfee® Virus Definitions
• MyWinLocker®1
Multimedia
• Acer Arcade™ Deluxe
• NTI Media Maker™
Gaming
• Oberon GameZone Acer Edition1
• WildTangent® Acer Edition1
Communication and ISP
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Utilities and tools
• Acer Accessory Store1
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091
• Netflix shortcut1
Optional items Acer Media Center remote control
1 GB / 2 GB / 4 GB DDR3 1066 MHz soDIMM module
9-cell Li-ion battery pack
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
1. Specifications vary depending on model.
2. 64-bit software is required to enjoy the advantages of 64-bit processing.
3. Up to 1 GB of available system memory may be allocated for system resource requirements.
4. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
5. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
6. Resolution/refresh rates depend on display capability and color/depth settings.
7. Dolby® is a registered trademark of Dolby® Laboratories. Dolby® Home Theater® is a trademark of Dolby® Laboratories.
8. Dolby® Pro Logic® and the double-D symbol are registered trademarks of Dolby® Laboratories.
9. Supports 7.1-channel surround sound and 2-channel stereo output (multiple streaming).
10. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and the operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
11. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11a/b/g/n and 802.11b/g standards.
12. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
13. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
14. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
15. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
Aspire 4745 Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows 7® Home Basic 64-bit2
CPU/chipset1 Intel® Core™ i7-620M processor (4 MB L3 cache, 2.66 GHz with Turbo Boost up to 3.33 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core™ i5-430M/i5-520M/i5-540M processors (3 MB L3 cache, 2.26/2.40/2.53 GHz with Turbo Boost up to 2.53/2.93/3.06 GHz, DDR3 1066 MHz, 35 W) supporting Intel® 64 architecture, Intel® Smart Cache
Intel® Core™ i3-330M/i3-350M processors (3 MB L3 cache, 2.13/2.26 GHz, DDR3 1066 MHz, 35 W) supporting Intel® 64 architecture, Intel® Smart Cache
Mobile Intel® HM55 Express Chipset
System memory1, 3, 5 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 8 GB using two soDIMM modules4
Display 14″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD, supporting simultaneous multi-window viewing via Acer GridVista™
16:9 aspect ratio
Super-slim design
Graphics Intel® HD Graphics with 128 MB of dedicated system memory, supporting Microsoft® DirectX® 10
Dual independent display support
16.7 million colors
External resolution / refresh rates6:
• VGA port up to 2560 x 1600: 60 Hz
• HDMI™ port up to 1920 x 1200: 60 Hz
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Optimized 3rd Generation Dolby® Home Theater®7 audio enhancement features, including Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Inverse Filtering, and Dolby® High Frequency Enhancer technologies8
High-definition audio support
Built-in microphone
S/PDIF (Sony/Philips Digital Interface)9 support for digital speakers
MS-Sound compatible
Storage One 160/250/320/500/640 GB or larger hard disk drives1, 10
Multi-in-1 card reader, supporting Secure Digital™ (SD), MultiMediaCard™ (MMC), Memory Stick® (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™1 /DVD-Super Multi double-layer drive
4X Blu-ray Disc™1 writer/DVD-Super Multi double-layer drive
8X DVD-Super Multi double-layer drive
Communication Acer video conferencing solution1, featuring:
• Acer Crystal Eye high-definition webcam with 1280 x 1024 resolution
WLAN1, 11, 12:
• Acer InviLink™ Nplify™ 802.11 b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1: Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control1 BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 342 (W) x 245 (D) x 21.1/29.1 (H) mm (13.46 x 9.64 x 0.83/1.14 inches)
2.23 kg (4.92 lbs.) with 6-cell battery pack13
Power adapter and battery1 ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 65 W AC adapter:
• 108 (W) x 46 (D) x 29.5 (H) mm (4.25 x 1.81 x 1.16 inches)
• 225 g (0.49 lbs.)13 with 180 cm DC cable
48.8 W 4400 mAh 6-cell Li-ion standard battery pack
Estimated battery life: Up to 6 hours14
ENERGY STAR®
Special keys and controls 86-/87-/91-key keyboard with inverted “T” cursor layout
Multi-gesture touchpad pointing device supporting scroll, pinch, rotate, flip
10 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Acer Programming key
Easy-launch keys: Communication®
Media control keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Four USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker jack with S/PDIF support
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer PowerSmart Manager1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google™ Setup
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial (Service Pack 2)
• Microsoft® Works SE 91
• Microsoft® Works 9
• Microsoft® Works 8.5
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite 2009 Trial15
• McAfee® Virus Definitions
• MyWinLocker®1
Multimedia
• Acer Arcade™ Deluxe
• NTI Media Maker™
Gaming
• Oberon GameZone Acer Edition1
• WildTangent® Acer Edition1
Communication and ISP
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Utilities and tools
• Acer Accessory Store1
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091
• Netflix shortcut1
Optional items Acer Media Center remote control
1 GB / 2 GB / 4 GB DDR3 1066 MHz soDIMM module
9-cell Li-ion battery pack
3-pin 90 W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
18. Specifications vary depending on model.
1. 64-bit software is required to enjoy the advantages of 64-bit processing.
2. Up to 1 GB of available system memory may be allocated for system resource requirements.
3. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
4. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
5. Resolution/refresh rates depend on display capability and color/depth settings.
6. Dolby® is a registered trademark of Dolby® Laboratories. Dolby® Home Theater® is a trademark of Dolby® Laboratories.
7. Dolby® Pro Logic® and the double-D symbol are registered trademarks of Dolby® Laboratories.
8. Supports 7.1-channel surround sound and 2-channel stereo output (multiple streaming).
9. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and the operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
10. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11a/b/g/n and 802.11b/g standards.
11. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
12. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
13. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
14. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
